Performance

Peak Power45kW
Max Torque240Nm
Acceleration (0-100km/h)4.9s
Max Speed120km/h
Max Lateral Acceleration1.6g

General

Mass with 68kg driver165kg Front / 165kg Rear
Front Track1100mm
Rear Track1080mm
Wheel Base1650mm
Dimensions2863mm Length, 1298mm Width, 1222mm Height
Chassis Construction4130 Chromoly Spaceframe

Suspension and Wheels

Suspension TypeDouble Wishbone, push rod activation with torsion bar and anti-roll bar
Tire Size, Compound and Make18x6", R25B Hoosier
Wheels (Width and Construction)10x6.25" 3 piece aluminium
Centre of Gravity Design height231mm

Tractive System

MotorEnstroj EMRAX 228
Motor ControllerUnitek, Bamocar D3
Accumulator Voltage470.4V
Accumulator Capacity6.6kWh

Drivetrain

Drive TypeChain drive with Drexler LSD
Final Drive Ratio3.35:1
