Performance

Peak Power12kW
Max Torque223Nm
Acceleration (0-100km/h)5.4
Max Speed80km/h
Max Lateral Acceleration1.5g

General

Mass with 68kg driver165kg Front / 165kg Rear
Front Track1100mm
Rear Track1080mm
Wheel Base1650mm
Dimensions2615mm Length, 1280mm Width, 1075mm Height
Chassis ConstructionCarbon Fibre 3/4 Monocoque with rear chromoly space frame

Suspension and Wheels

Suspension TypeDouble Wishbone, push rod activation with torsion bar and anti-roll bar
Tire Size, Compound and Make18x6", R25B Hoosier
Wheels (Width and Construction)10x6.25" 3 piece aluminium
Centre of Gravity Design height231mm

Tractive System

Motor2x Motenergy ME-0913 BLDC
Motor Controller2x Kelly KHB 14401
Accumulator Voltage122V Full Charge, 111V Nominal
Accumulator Capacity4.44kWh

Drivetrain

Drive TypeDual Independent chain driven
Final Drive Ratio3.1:1
